DRS Series Variable Speed Rotary Screw
Champion Pneumatic — Variable Speed Drive
10–200 HP
Variable Speed
Up to 35% Energy Savings
100% Duty Cycle
The Champion DRS Series uses a variable frequency drive (VFD) to continuously modulate motor speed and match compressed air output precisely to actual system demand. This eliminates the energy waste associated with fixed-speed compressors running at full speed during partial load periods — a common scenario in most facilities.
For operations with fluctuating air demand, the DRS Series can reduce energy consumption by up to 35% compared to a comparable fixed-speed unit. The soft-start capability also reduces mechanical stress and extends component life. Available from 10 to 200 HP.
Standard Features
- ✓ Integrated variable frequency drive (VFD)
- ✓ Up to 35% energy savings vs. fixed speed
- ✓ Soft-start reduces electrical demand charges
- ✓ Precise pressure control (±1 PSI)
- ✓ Sound-attenuated enclosure
- ✓ Advanced electronic controller with data logging
- ✓ Premium efficiency TEFC motor
- ✓ 100% continuous duty rated
DRS Series Specifications
| Specification | Details |
|---|---|
| HP Range | 10 – 200 HP |
| Type | Oil-flooded rotary screw, variable speed |
| Drive | Variable frequency drive (VFD) |
| Energy Savings | Up to 35% vs. fixed speed |
| Pressure Range | 100, 125, 150 PSI (model dependent) |
| Pressure Control | ±1 PSI precision control |
| Voltage Options | 230V/3Ph, 460V/3Ph, 575V/3Ph |
| Cooling | Air-cooled with thermal bypass |
